Product Details
| Total pressure | 1000KN |
| Specific pressure | 2.6kgf/cm² |
| Working layer | 2 |
| Hot platen size and No. | 3-3000x1300x42mm(covered with mylar film) |
| Hot platen opening | 170mm |
| Cylinder No. & diameter | 6-φ85mm |
| Voltage | 3PH 380V 50HZ |
| Heating method | Electricity heating thermal oil |
| Installation power | 40.75KW |
| Platen opening way | Automatic |
| Max. working temperature | 120°C |
| Loading way | Length side, Manually |
