Product Details
| Model | LGMY-200IISD |
| Machine size (mm) | 3500X1400X1300 |
| Machine weight | 2T |
| Maximum turning length (mm) | 2000 |
| Maximum turning diameter of upper shaft (mm) | 300 |
| Biaxial maximum turning diameter (mm) | 150 |
| Maximum length of engraving and milling (mm) | 1850 |
| Maximum engraving and milling diameter (mm) | 200 |
| Spindle power | 7.5KW |
| Spindle speed | 0~3500r/min |
| Engraving and milling axis power | 2.2KW |
| Number of tool holders | 2 |
| Inverter | HIDELY 7.5KW |
| Accuracy (mm) | ±0.04 repeat positioning 0.02 |
| Diameter running speed (mm/min) | Stepping: ≥5000 |
| Length running speed (mm/min) | Stepping: ≥8000 |
| Oil injection system | Standard |
| Clipping method | Pneumatic clamping |
| Voltage | AC:380V 50HZ |
| Applicable software | AutoCAD, Jingdiao, CAXA, Sinicized DBF, etc. |
