DOUBLE SIDE PLANER QMB206A

Introduction:

Professional solution: double-sided planer and the setting thickness for the wood which the thickness is under the 210mm.

Φ125mm dia. cutter spindle, double-surface planing, stable performance and good processing quality.

Inquire Now

Product Details

Specifications		QMB206A\A-H
Working width	mm	50~635
Working thickness	mm	8~210
Min.working length	mm	310
Max cutting depth (Upper\Botom)	mm	7\5
Feeding speed	m/min	6~30
Rotation speed of spindle	r/min	4600
Spindle cutting dia	mm	Φ135
Total power	kW\HP	38.3\51
Spindle motor	kW\HP	\
Top spindle motor	kW\HP	18.5\25
Bottom spindle motor	kW\HP	15\20
Front blade spindle motor	kW\HP	\
Back blade spindle motor	kW\HP	\
Feeding motor	kW\HP	4 \5.5
Lifting motor	kW\HP	0.75\ 1
Suction hood Dia	mm	4xΦ150
Overall dimensions	mm	3250x1530x1850
Weight	kg	4500
