Product Details
| Specifications | ML9323DM | |
| Working width | mm | 230 |
| Working thickness | mm | 15~90 |
| Min.Working length (single/continuous) | mm | \ |
| Bottom cutter dia | mm | Φ125 |
| Right&left vertical cutter dia | mm | \ |
| Upper cutter dia | mm | Φ125~Φ160 |
| Left&right saw blade Dia | mm | \ |
| Bottom spindle | KW\HP | 7.5\10 |
| Right&left vertical spindle | KW\HP | \ |
| Up horizontal spindle | KW\HP | 7.5\10 |
| Left, right saw spindle motor | KW\HP | \ |
| Saw spindle Dia | mm | Φ50 |
| Saw spindle speed | r/min | 4500 |
| Planer spindle Dia | mm | Φ40 |
| Planer spindle speed | r/min | 6800 |
| Upper saw blade dia | mm | \ |
| Bottom saw blade dia | mm | Φ200~Φ350 |
| Feeding speed | m/min | 6~35 |
| Totol power | KW\HP | 42.5\57 |
| Up saw spindle motor | KW\HP | \ |
| Bottom saw spindle motor | KW\HP | 22\30 |
| Feeding motor | KW\HP | 4\5.5 |
| Rear auxiliary feeding motor | KW\HP | \ |
| Lifting motor for upper and bottom saw spindle | KW\HP | \ |
| Beam lifting motor | KW\HP | 0.75\1 |
| Saw spindle lifting motor | KW\HP | 0.75\1 |
| Air supply pressure | MPa | 0.4~0.6 |
| Suction hood Dia | mm | 5xΦ140 |
| Overall dimensions | mm | 3380x1450x1800 |
| Weight | KG | 3450 |
