Product Details
| Model | NCB612DPL |
| Panel length | 250-2800mm |
| Panel width | 30-1200mm |
| Panel thickness | 10-60mm |
| Max speed | 135/135/75/30m/min |
| Main spindle power | 3.5kw×4 |
| Max rotation speed | 18000rpm |
| Upper vert.drill | 12×4 |
| Upper vert. drill | X direction：4×2 Y direction：2×2 |
| Lower vert.drill | 9X2 |
| Rotation speed | 5000rpm |
| Dust collector | Top dust collectorφ150mm×2 Bottom dust collectorφ125mm |
| Total power | 48.36kw |
| Overall dimension | 7300×3530×2325mm |
| Net weight | 8250kg |
