Product Details
| Model | NCB612DXL |
| Panel length | 250-2800mm |
| Panel width | 50-1200mm |
| Panel thickness | 10-60mm |
| Max speed | 135/135/75/30m/min |
| Main spindle power | 3.5kw×2 |
| Max rotation speed | 18000rpm |
| Upper vert.drill | 18×2 |
| Upper vert. drill | 16 × 2 X: 4×2 Y: 4×2 10 |
| Lower vert.drill | 10 |
| Rotation speed | 5000rpm |
| Dust collector | Top dust collectorφ150mm×2 Bottom dust collectorφ125mm |
| Total power | 24.6kw |
| Overall dimension | 7390×2806×2325mm |
| Net weight | 4710kg |
