Product Details
| Model | NCB612DXT |
| Panel size（drilling+grooving） | Thickness：10-50mm Width：30（groove 40）-1200mm Length： 200- 3000mm |
| Panel size（routing） | Thickness 12-50mm Width 65-1200mm Length 250- 2400mm |
| Control system | SYNTECH |
| Max speed（X/U/Y/Z） | 135/135/75/30m/min |
| Spindle power | Top：5.5kw，Bottom：3.5kw |
| Max rotation speed | 18000rpm |
| Top vert.drill | 18×2 |
| Top horiz. drill | X direction：4×2 Y direction：2×2 |
| Lower vert.drill | 9 |
| Rotation speed | 5000rpm |
| Dust collector | Top φ200mm*2,Bottom φ125mm |
| Total power | 22.3kw |
| Overall dimension | 6150×2906×2325mm |
| Net weight | 3850kg |
