TENONING MACHINE QMX8025M 8 SPINDLES CNC DOUBLE END
Introduction:
Professional solution: used to make tenon&groove at the two ends of the wood piece ,or square the wood,suitable for making wooden door,big board working,etc.
The machine bed is made of quality cast iron,heavy and stable;long working feed table;the third spindle has jump-cut function;touch screen control auto width setting with ball srew rod transmission,highly precision working.
Inquire Now
Product Details
| Specifications | QMX8025M | |
| Working width | mm | 300~2500 |
| Working thickness | mm | 10~120 |
| Feed block spacing | mm | 500 |
| Feeding speed | m/min | 6~36 |
| Saw shaft speed | r/min | 3000 |
| Milling axis speed | r/min | 7500 |
| Buckle milling spindle speed | r/min | \ |
| Upper saw blade diameter | mm | Φ200~Φ300 |
| Lower saw blade diameter | mm | Φ160~Φ200 |
| Milling cutter diameter | mm | Φ108~Φ180 |
| Buckle milling blade diameter | mm | \ |
| Saw shaft\milling shaft diameter | mm | Φ30\Φ40 |
| Total motor power | KW\HP | 47.2\63 |
| Upper saw blade motor | KW\HP | 2x5.5\7.5 |
| Lower saw blade motor | KW\HP | 2x2.2\3 |
| Jump cut milling shaft | KW\HP | 2x5.5\7.5 |
| Milling axis | KW\HP | 2x7.5\10 |
| Buckle milling shaft power | KW\HP | \ |
| Feeding motor | KW\HP | 4\5.5 |
| Width adjusting motor | KW\HP | 1\1.5 |
| Press lifting motor | KW\HP | 2x0.37\0.5 |
| Vacuum port diameter | mm | 8xΦ120 |
| Machine dimensions | mm | 4880x4650x1900 |
| Machine weight | KG | 6500 |
